Technické specifikace
| HARDWARE FEATURES | |
| Interface | 1 Gigabit Ethernet Port |
| Button | • WPS Button • Reset Button |
| Input Power | 100-240V~50/60Hz |
| Max. Power Consumption | 10W |
| Dimensions ( W x D x H ) | 2.9×1.8×4.9 in. (74.0×46×124.8 mm) |
| Antenna | 2 Internal Antennas |
| WIRELESS FEATURES | |
| Wireless Standards | • IEEE 802.11a/n/ac/ax 5GHz • IEEE 802.11b/g/n/ax 2.4GHz |
| Frequency | 2.4GHz and 5GHz |
| Signal Rate | • 574 Mbps at 2.4 GHz • 1201 Mbps at 5 GHz |
| Working Modes | Range Extender/Access Point |
| Reception Sensitivity | 5 GHz: 11ax HE80 MCS0: -87dBm, 11ax HE80 MCS11: -56dBm 11a 6Mbps: -93dBm, 11a 54Mbps: -75dBm 11ac HT20 MCS0: -92dBm, 11ac HT20 MCS8: -70dBm 11ac HT40 MCS0: -90dBm, 11ac HT40 MCS9: -66dBm 11ac HT80 MCS0: -87dBm, 11ac HT80 MCS9: -62dBm 2.4 GHz: 11ax HE40 MCS0: -93dBm, 11ax HE40 MCS11: -63dBm 11g 54Mbps: -77dBm, 11n HT20 MCS7: -75dBm 11n HT40 MCS7: -72dBm |
| Wireless Functions | • Enable/Disable Wireless Radio • DFS (the latest firmware and hardware version is required) • Access Control • LED Control • Power Schedule • Wi-Fi Coverage Adjustment |
| Wireless Security | • 64/128-bit WEP • WPA/WPA2-PSK encryptions |
| Transmission Power | CE: • 2.4 GHz ? 20 dBm • 5 GHz ? 30 dBm |
| Mesh Technology | EasyMesh |
| OTHERS | |
| Certification | CE, RoHS |
| Package Content | • Wi-Fi Range Extender RE660X • Quick Installation Guide |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
| Environment | • Operating Temperature: 0?~40? (32? ~104?) • Storage Temperature: -40?~70? (-40? ~158?) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing |
